Enquiry Pro
Hydraulic Pump
- Product: A10VG Axial Piston Variable Hydraulic Pumps
- Models: A10VG18, A10VG28, A10VG45, A10VG63
- Pump Type: Axial Piston, Variable, Closed Circuit
- Displacement: 18, 28, 45, 63 cm³/rev (1.09–3.84 in³)
- Flow Rate: 72–189 L/min
$800.00
USD - per unit
Product Description
A10VG Hydraulic Pumps Series. This series is a high-quality quality reliable solution to high-demand hydraulic systems. It is a hydraulic piston pump with high performance at 72189 L/min flow rates and a pressure of up to 350 bar (5076 psi). It can be adjusted to a specific flow and power output with its varying displacement of 18 -63 cm 3/rev, which makes it the perfect option for industrial machines, excavators, and heavy equipment.
These are hydraulic pumps and motors designed to operate continuously and intermittently, offering optimized torque and power to heavy-duty applications. The A10VG has the capability of high pressure hydraulic piston pump, which guarantees efficiency in systems with high sensitivity and responsiveness.
The series also has optional boost pump functions (Vg max 1863 cm 3/rev, Vg Sp 5.514.9 cm 3 at 20 bar) to assist with starting and auxiliary operations to help increase the reliability of the system. Its small and light structure (18-85 kg based on size) makes it easy to install, and the ordinary size and sturdy construction make it a long-lasting construction.
You can either require a hydraulic pump motor or a standby electric hydraulic pump; the A10VG series fulfills the multi-purpose principles of the industrial sector. It is also easy to maintain due to the use of high-quality materials and precision engineering, and the hydraulic pump parts are easily available for repair or upgrade.
To the companies that seek to purchase quality hydraulic pumps for sale, the A10 VG series offers both high efficiency and technology with flexibility to multiple hydraulic systems, making sure that your machines are running well and efficiently.
Product Information
- Product: A10VG Axial Piston Variable Hydraulic Pumps
- Models: A10VG18, A10VG28, A10VG45, A10VG63
- Pump Type: Axial Piston, Variable, Closed Circuit
- Displacement: 18, 28, 45, 63 cm³/rev (1.09–3.84 in³)
- Flow Rate: 72–189 L/min
- Pressure Range: 300–350 bar (4351–5076 psi)
- Torque: 86–301 Nm
- Speed Range: 3000–4000 rpm (optional)
- Weight: 18–85 kg (Small 18–25 kg, Medium 32–45 kg, Large 55–85 kg)
- Power: Standard (W) per displacement
- Max Geometric Displacement: 18–63 cm³/rev
- Rotary Stiffness: 0.00093–0.0056 Nm/rad
- Filling Capacity: 0.45–1.1 L
- Moment of Inertia: 0.00093–0.0056 kg·m²
- Dimensions & Structure: Standard
- Other specs: Continuous & intermittent max RPM, torque at various pressures, flow at Vg max, etc.
Product feature
Maximum Geometric Displacement: Ranging from 18–63 cm³/rev, this allows precise adjustment of flow and power output according to system requirements. It ensures flexibility for a wide variety of hydraulic applications and operational demands.
Boost Pump Options: The Vg max of 18–63 cm³/rev and Vg Sp of 5.5–14.9 cm³ at 20 bar provide reliable support for startup and auxiliary functions. These options enhance system responsiveness and maintain consistent performance under varying conditions.
Rotary Stiffness: High shaft end stiffness, ranging from 0.00093–0.0056 Nm/rad, ensures precise and stable operation, even under varying load conditions. This allows the pump to maintain smooth performance in demanding hydraulic systems.
Filling Capacity: With a compact and lightweight design, the filling capacity of 0.45–1.1 L makes installation and maintenance easier. Its efficient volume ensures proper lubrication and quick readiness for operation.
Moment of Inertia: The moment of inertia of 0.00093–0.0056 kg·m² enables fast response to sudden load changes, improving the pump’s dynamic performance. This ensures high efficiency and consistent flow in variable conditions.
Power & Torque Performance: Engineered for both continuous and intermittent operation, the pump delivers optimized power and torque across all speeds. This makes it reliable for heavy-duty machinery that requires consistent hydraulic output.
Construction: Built with robust materials and standard dimensions, the pump is durable and easy to integrate into a wide range of machinery. Its strong design minimizes wear and extends service life under high-pressure conditions.
Versatile Applications: Perfectly suited for excavators, industrial machines, and heavy equipment, this pump handles demanding tasks efficiently. Its adaptability allows use in multiple hydraulic systems across construction, mining, and manufacturing sectors.
